FSE’s slurry ice machines are designed to produce a semi-liquid mixture of ice crystals and water It is known as slurry ice. It offers rapid cooling and excellent heat transfer capabilities. This type of ice is particularly effective for industries such as fishing, seafood processing, and food preservation. In these industries, maintaining product freshness is critical. The smooth, fluid consistency of slurry ice allows it to envelop products, providing uniform cooling and preventing damage to delicate items like seafood.
Slurry Ice Machine Parameters | ||||||
Unit | Standard Ice | Nominal | Required | Power | ||
Model | Condensing | Ice-making Media | ||||
S50WI40 | Water | Seawater or | 40% | 5 | 7739 | 5.5 |
S100WI40 | 10 | 15477 | 9.8 | |||
S150WI40 | 15 | 23216 | 19.2 | |||
S200WI40 | 20 | 30955 | 25 | |||
S250WI40 | 25 | 36893 | 31.25 | |||
S350WI40 | 35 | 54170 | 42.2 | |||
Slurry Ice Storage Bucket Parameters | ||||
Model | SIT1 | SIT2 | SIT4 | SIT7 |
Nominal Storage | 1m³ | 2m³ | 4m³ | 7m³ |
Dimension (mm) | Φ1200*1350 | Φ1200*2000 | Φ1500*2500 | Φ1500*4000 |
Water(ice)Inlet Dimension | DN25 | DN40 | DN50 | DN50 |
Ice Outlet Dimension | DN25 | DN40 | DN40 | DN40 |
Insulation | Rubber insulation | Polyurethane foam insulation | ||
Ice Pump Power | 0.4KW | 0.75KW | 0.75KW | 0.75KW |
Mixer's Motor Power | 0.55KW | 0.75KW | 1.1KW | 1.5KW |
Power Specification | 380V/50HZ/3P | |||
Meat processing
Aquatic products processing
Temperature reduction project
Cold storage project
Supermarket or other commercial usage
Vegetable preservation
Fishery industry
High Visibility: Easy observation of the ice-making process.
User-Friendly: Simple operation, easy cleaning, and maintenance.
Safe and Reliable: Built to pressure vessel standards. Corrosion-resistant control panels ensure safety and durability.
Efficient and Energy-Saving: Prevents ice blockage, ensuring high efficiency and low energy use.
Wide Applicability: Suitable for most marine environments. Capable of making ice from seawater or brine (minimum concentration 2.9%). Ideal for installation in confined spaces like ship cabins.
